| Items |
Details |
Remark |
|
Processor |
Intel Quad Core @ 1.44GHz |
CherryTrail-T3 Z8350 |
| eMCP |
DDR3L |
2GB |
| eMMC |
16GB |
| Operating System |
Win10 IoT Ent LTSB 2016 |
|
| Display resolution |
5.0 inch,720x1280Pixels |
|
| Touch panel |
5.0 inch, Capacitor Touch Panel (multipoint) |
full lamination |
| SCM-part Features |
Processor for secure solution |
ARM Cortex-M3 |
|
| Thermal Printer |
High speed ,Low noise,Low voltage |
|
| Width: 58mm ,Diameter: 30mm |
| with 2 x sensor for lid open and paper out; |
| RFID/13.56MHz |
ISO 14443 Type A/B |
PN518 |
| Behind HOME button zone of read/write capability |
| MSR |
ISO7811-Track 1,2,3 (Bi-directional) |
|
| PSAM Card |
PSAM Slot x1 |
|
| BEEP |
Yes, |
|
| Scanner |
2D |
Support 1D & 2D bar-code scanning |
|
| LEDs |
Power State Indicate |
1 PCS LEDs(Red) |
|
| Indicator |
Wireless Indicate |
1 PCS LEDs(Red) |
|
| swiping card Indicate |
1 PCS LEDs(Red) |
|
| BatteryCharge Indicate |
1 PCS LEDs(Red) |
|
| Wireless |
WLAN |
802.11a/b/g (a/b/g/n as an option) |
|
| Bluetooth |
BT 2.0 + EDR |
|
| 2G\3G\4G |
Support 2G\3G\4G Communication |
3G:UC20-E |
| 4G:EC25 (Option) |
| GPS |
GPS |
Integration on UC20\EC25 |
| SIM Card |
1 SIM Slot |
|
| Power supply |
Adaptor |
DC 9V\3A |
|
| Battery |
7.4V/ 2500mAh Li-ion（Removable |
|
| Stand-by Battery |
3.7V/ 2400mAh Li-ion（Built-in） |
Support minimum 120 minutes running time without main battery in position; |
| External interface |
USB OTG |
Micro USB × 1 |
|
| USB HOST |
Micro USB x1 (male plug) |
|
| RS232 Port |
Micro USB x1 |
|
| Micro SD |
Micro SD slot × 1 |
Support TF Card |
| Home key |
Home key × 1 |
|
| Reset Key |
Reset key × 1 |
|
| Scan side Key |
Scan key × 2 |
|
| Environmenta |
Operation temp. |
0℃-- 50℃ |
|
| Storage temp |
-20℃--70℃ |
|
| Relative humidity |
10% ~ 90%, non-condensing |
|
| Operation system Power On/Off |
Power key x1 |
|
| Press on 2~3s power on/off |
| Physical (L x W x H) |
221.75 * 89 * 64.5 mm |
|
| Weight |
920g (with battery inside) |
Battery (7.4V/2000mah）= 68.6g |
